WX10
1" general purpose pump
- 32 gal./min capacity
- Weighs only 13 lbs.
- Garden hose adaptor, suction hose, clamps, and strainer included
Features
Perfect for homeowners, gardeners, boat owners, and more
The WX10 is lightweight, compact, and easy to use.
Easy starting Honda mini 4-stroke commercial engine
The durable Honda GX series commercial grade engine is easy starting and provides ample power for the toughest conditions.
Lightweight
At only 13 lbs., the WX10 is easily portable.
Advanced pump design for superior durability and performance
The WX10 has been completely redesigned by Honda R & D for quality and durability. Improvements to the impeller, case, engine frame bed, and other pump components add to the WX10's impressive durability and performance.
Garden hose adaptor, suction hose, clamps, and strainer included
Comes with everything you need to get started. Just hook up a garden hose, and you're ready to pump.
3 position discharge port
The WX10's discharge port can be changed to 3 different positions, providing added flexibility.
Standard transport handle
The WX10 is easy to carry wherever you need it.
32 gal./min capacity
Uses regular gasoline - no mixing of oil and gas!
Easier priming
The priming port is thoughtfully designed to make priming easier and reduce drips and spills.
Specifications
Engine
GX25
Displacement
25cc
Bore and stroke
1.4" x 1.0"
Compression Ratio
8.0:1
Oil Alert
N/A
Pump Type
General purpose Centrifugal Self-priming
Volute
Aluminum
Impeller
Aluminum
Mechanical Seal (Pump case / impeller)
Carbon/Ceramic
Priming time
80 sec. at 16.4 ft.
Drive system
Direct
Discharge capacity
32 gal./min.
Suction port diameter
1.0" NPT
Discharge port diameter
1.0" NPT
Total head lift
121 ft.
Suction head lift
26 ft.
Maximum pressure
52 psi
Solids handling
N/A
Dimensions (LxWxH)
13.4"x8.7"x11.6"
Dry weight
13 lbs.
Fuel Capacity
0.56 qt
Run Time @ Max Discharge
0.9 hr
Strainer Part #
78325-YB0-711
Residential Warranty
2 years
Commercial Warranty
1 year
Pump Performance
Accessories
Hoses, strainers, couplers, and clamp sets are available.
